CHMER CNC Series H32C Small Hole Drilling EDM
CHMER CNC Series H32C Small Hole Drilling EDM
Description
CHMER offers four models of their affordable CNC EDM Drillers; from the smallest H32C a compound table design, through their Gantry style models: H64C, H86C and H1080L. The bridge style utilizes a linear motor drive and Fagor glass scales on the longer Y-axis and Panasonic AC servo motor and optional glass scale on the shorter X-axis. The bridge style allows for large and heavy workpieces to EDM drill on the fixed worktable. The electrode range is from .2 - 3.0 mm with option to go up to 6.0 with the ER spindle and ER collets.
Optional Automatic Electrode Changer 10 or 20 position, and optional guide changer 5 positions are available.
The CNC controller can also control optional B or AB indexers from various index manufacturers: MMK, Parkson, Shin Jin and others. Blind hole, polarity switching during machining and hard metal drilling are standard features. A complete water dielectric system is included with filtration.
Includes Installation and On-site Training at no additional cost.
Specifications
| Manufacturer | CHMER EDM of Taiwan |
| Model | H32C |
| Year | 2026 |
| Condition | New |
| Stock Number | H32C- |
| Travels (X Y): | 350 x 250 mm / 13.8" x 9.8" |
| Travels Z axis ram: | 400 mm / 13.4" |
| Travels W axis: | 250 mm / 9.8" |
| Worktable Size (WxD) | 660 x 320 mm / 25.7" x 12.7" |
| Max. workpiece size: (WDH): | 800 x 400 x 250 mm / 31.5" x 13.8" x 9.8" (inside splash guards) |
| Max. workpiece weight: | 180 kg / 396 lbs. |
| Total Footprint | 2000 x 1875 x 2100 mm / 79" x 74" x 83" |
| Machine weight: | 900 kg / 1,984 lbs. |
