CHMER RX853F/S Flushing or Submerged
CHMER RX853F/S Flushing or Submerged
orCall 888-289-3367
Description
The CHMER RX Series are the larger models of the G Series. The RX Series features a linear motor drive and Fagor glass scale on the longer axis and a ball screw with AC servo motor drive and glass scale on the shorter axis.
Installation and On-site Training are included.
Specifications
| Manufacturer | CHMER EDM of Taiwan |
| Model | RX853F/S |
| Condition | New |
| Travels (X Y): | 800 x 500 mm / 31.5" x 19.7" |
| Travels (U V Z): | 150 x 150 x 300 mm / 5.9" x 5.9" x 11.8" |
| Max. workpiece size: (WDH): | 1210 x 800 x 295 mm / 47.6" x 31.5" x 11.6" |
| Max. workpiece weight: | 2000 kg Flushing-1000 kg Submerged / 4400-2200 lbs. |
| Outside dimensions (WxDxH): Flushing | 2400 x 2800 x 2350 mm / 94.5" x 110.2" x 92.5" |
| Outside dimensions (WxDxH): Submerged | 3150 x 3500 x 2350 mm / 124" x 137.8" x 92.5" |
